Mut Solar

VMR 2 WAY SOLAR

MOTORIZED 2-WAY ZONE VALVES

MAIN CHARACTERISTICS

VMR valves are motorized valves used in home applications and small installations to control the flow of hot and cold water. The 2 ports are designed for On-Off zone controll of domestic systems. The valve, thanks to its cylindrical shut-off, shunts flow which is independent from the differential pressure between ports. This shut-off can have two operating positions depending on how the electric motor that moves it is powered. The head of the valve can be removed without draining up the plumbing system: this makes valve maintenance quick and flexible. Without the head the valve is normally closed (Fig.1).
An auxiliary microswitch can be installed on request and be activated when the valve is switched. Valves have an external lever for manually positioning the shut-off in its central position.


Download
product details
specification summaries
VMR 2-WAY Datasheet 2014-03-06 it, en, de, fr, es pdf go
